| Supply Ability : | 5000 Ton/Tons per Week |
| Price : | $850.00/tons 1-4 tons |
| Delivery Time : | 7 Day |
| MOQ : | 1 Ton |
Product Name | galvanized steel pipe/iron rectangular tube | ||||||
Standard | ASTM, DIN, GB, JIS, ASTM A513-2007, DIN EN 10208-1-1998, DIN EN
10216-1-2004, GB/T 3094-2000, JIS G3465-2006, JIS G3466 | ||||||
Material | Q195 / Q215 / Q235 / Q345 / S235JR / GR.B-D/STK500 | ||||||
Size | Length :1m --12m, Diemeter :21.5--406.4 mm, Thickness :0.6mm -- 20mm | ||||||
Shape | Round/Square/Rectangular | ||||||
Yield Strength | 360-380Mpa | ||||||
Tensile Strength | 560-580Mpa | ||||||
Bend Test | Qualified | ||||||
Impact Value | V-notch | ||||||
Usage /Application | Building industry machinery/Construction of greenhouses | ||||||
Price terms | FOB,CRF,CIF,EXW all acceptable | ||||||
Samples | Free samples are provided but the fright is borne by the buyer | ||||||
Regular Sizes of Galvanized Steel Pipe | ||||||||||
DN | NB | OD (mm) | WT (mm) | Pcs/Bundle | Regular Length: 5.7m, 5.8m, 6.0m, 6.4m. Besides, we can make to order for you according to your requested length. | |||||
15 | 1/2" | 19mm-21.3mm | 1.5mm-3.0mm | 217 | ||||||
20 | 3/4" | 25mm-26.9mm | 1.5mm-3.0mm | 169 | ||||||
25 | 1" | 32mm-33.7mm | 1.5mm-3.0mm | 127 | ||||||
32 | 1.1/4" | 40mm-42.4mm | 1.5mm-4.0mm | 91 | ||||||
40 | 1.1/2" | 47mm-48.3mm | 1.5mm-4.0mm | 91 | ||||||
50 | 2" | 58mm-60.3mm | 1.5mm-4.0mm | 61 | ||||||
65 | 2.1/2" | 73mm-76.1mm | 1.5mm-4.0mm | 37 | ||||||
80 | 3" | 87mm-88.9mm | 1.5mm-9.5mm | 37 | ||||||
100 | 4" | 113mm-114.3mm | 2.0mm-9.5mm | 19 | ||||||
125 | 5" | 140mm-141.3mm | 3.0mm-9.5mm | 19 | ||||||
150 | 6" | 165mm-168.3mm | 3.0mm-12.0mm | 19 | ||||||
200 | 8" | 219.1 | 3.2mm-12.0mm | 7 | ||||||
250 | 10" | 273.0 | 3.2mm-12.0mm | 5 or 1 | ||||||
300 | 12" | 323.9mm-325mm | 6.0mm-15mm | 3 or 1 | ||||||
350 | 14" | 355mm-355.6mm | 8.0mm-15mm | 1 | ||||||
400 | 16" | 406.4mm | 8.0mm-20mm | 1 | ||||||
450 | 18" | 457mm | 9.0mm-23mm | 1 | ||||||
500 | 20" | 508mm | 9.0mm-23mm | 1 | ||||||
550 | 22" | 558.8mm | 9.0mm-23mm | 1 | ||||||
600 | 24" | 609.6mm | 9.0mm-23mm | 1 | ||||||
Square Hollow Section (SHS) | WT(mm) | Rectangular Hollow Section(RHS) | WT(mm) |
16*16 | 0.8-1.5 | 20*40 | 0.8-2.0 |
19*19 | 0.8-2.0 | 25*50 | 0.8-2.0 |
20*20 | 0.8-2.0 | 30*40 | 0.8-2.0 |
25*25 | 0.8-2.0 | 30*50 | 0.8-2.0 |
30*30 | 0.8-2.0 | 37*57 | 0.8-2.0 |
32*32 | 0.8-2.0 | 40*60 | 0.8-2.0 |
35*35 | 0.8-2.0 | 37*77 | 0.8-2.0 |
38*38 | 0.8-2.0 | 25*75 | 1.0-2.0 |
40*40 | 0.8-2.0 | 40*80 | 1.0-2.2 |
50*50 | 0.8-2.0 | 50*100 | 1.0-2.2 |
60*60 | 1.0-2.2 | 50*75 | 1.0-2.2 |
80*80 | 1.0-2.2 | 38*75 | 1.0-2.2 |
100*100 | 1.0-2.3 | 50*75 | 1.0-2.2 |
|
|
